MacIQ WM

PLUM ELECTRONICS
telemetry
module IoT

IoT module dedicated for water meters MacIQ WM

MacIQ WM is a compact telemetry module which is an element of stationary water meter reading system.
A simple “Plug&Play” solution, that does not require transmission components or building its own infrastructure. Use of modern technology dedicated for the IoT trend with increased radio signal propagation and focus in particular on coverage. The device operates in licensed telecommunication networks in NB-IoT or LTE Cat.M1 standard.
The module ensures effective data transmission even from difficult locations. Adapted to the real-time system requirements — immediate reporting of an incident. It allows to improve water network efficiency and generating of reports.
The device meets the requirements for installation in high humidity and full immersion conditions.

Why you should choose
MacIQ WM module?

  • effortless installation directly on water meter without damaging legalization seals
  • more than 10 years of operation on a built-in battery
  • detection of magnetic interference and attempt to disassemble the device from the water meter
  • possibility to set alarms and warnings related to the minimum and maximum flow rate
  • housing adapted to work in full immersion
  • efficient data transmission from hard-to-reach locations thanks to NB-IoT or LTE Cat. M communication technology
  • immediate dispatch of alarms after the occurrence of an event
  • no need to build your own transmission infrastructure
  • compatibility with water meters of leading manufacturers
  • possibility to equip with optional antenna with 2.5m cable

alarms

interference with magnetic and electromagnetic fields

backflow

potential leakage

exceeded flow max. 10 minutes

configurable maximum/minimum flow alarm thresholds

battery discharge

implementation versions
MacIQ WM module

internal antenna

  • designed for installation in dry locations above ground level ground level
  • not suitable for operation in full immersion and heavy wetness
  • protection class IP 65

tail antenna

  • designed for installation in places such as shallow non-submersible wells
  • designed to work in full submersion – report sent only after lowering of water level below the antenna
  • protection class IP 68

external antenna

  • designed for installation in water meter wells and locations with poor coverage
  • designed to work in full submersion – reports until the antenna is submerged
  • protection class IP 68
  • version equipped with SMA connector available on request

technical data

dimensions:
109,2 x 40 x 44,7 mm
housing material:
polycarbonate
work temperature range:
min. -5°C, max. +50°C
display:
optical display showing connection to the server
communication with water meter:
induction coils allowing direct installation on water meter

accessories

eWebtel

Measuring data acquisition system
